PIC16F1618T-I/SS
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
7KB Flash,512 RAM,32MHz Int. Osc,10-bit ADC,ZCD,WWDT,CRC
PDF
/
Inventory: 2419
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2014
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PIC16F1618
Operating Supply Voltage 5.5V
Interface I2C, LIN, SPI, UART, USART
Memory Size 7kB
Oscillator Type Internal
Number of I/O 18
RAM Size 512 x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 7KB 4K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 12x10b; D/A 1x8b
Has ADC YES
DMA Channels NO
Data Bus Width 8b
Number of Timers/Counters 5
Number of UART Channels 1
Number of ADC Channels 8
Number of PWM Channels 2
Number of USB Channels 0
Dimensions
Height 2mm
Length 7.2mm
Width 7.8mm
Compliance
RoHS Status ROHS3 Compliant
