PIC16F1613-E/P
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB FLASH 14DIP
PDF
/
Buying Options
Total Price: USD $1.17
Unit Price: USD $1.168481
≥1 USD $1.168481
≥200 USD $0.452951
≥500 USD $0.437196
≥1000 USD $0.429318
Inventory: 1652
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 14-DIP (0.300, 7.62mm)
Number of Pins 14
Weight 1.620005g
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2013
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Terminal Position DUAL
Supply Voltage 3V
Frequency 32MHz
Base Part Number PIC16F1613
Supply Voltage-Max (Vsup) 5.5V
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 12
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
Screening Level TS 16949
Number of UART Channels 0
Number of ADC Channels 8
Number of PWM Channels 2
Dimensions
Height 3.302mm
Length 26.162mm
Width 3.302mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
