PIC16F15354-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB FLASH 28SOIC
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.1528
≥1 USD $1.1528
≥10 USD $1.0736
≥100 USD $0.968
Inventory: 1063
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 17.9mm
Height Seated (Max) 2.65mm
Technical
Screening Level TS 16949
On Chip Program ROM Width 14
ROM (words) 4096
DAC Channels YES
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 24x10b; D/A 1x5b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 7KB 4K x 14
Core Size 8-Bit
Program Memory Type FLASH
Clock Frequency 32MHz
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 512 x 8
Speed 32MHz
Number of I/O 25
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code R-PDSO-G28
Base Part Number PIC16F15354
Terminal Pitch 1.27mm
Supply Voltage 3V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
HTS Code 8542.31.00.01
Additional Feature ALSO OPERATES IN 16MHZ AT MIN SUPPLY VOL 2.3V
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2009
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 2 Weeks
