PIC16F15354-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB FLASH 28QFN
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.138162
≥1 USD $1.138162
≥10 USD $1.073741
≥100 USD $1.012961
≥500 USD $0.955617
≥1000 USD $0.901531
Inventory: 1452
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Height Seated (Max) 1mm
Technical
Screening Level TS 16949
On Chip Program ROM Width 14
DAC Channels YES
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 24x10b; D/A 1x5b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 7KB 4K x 14
Core Size 8-Bit
Program Memory Type FLASH
Clock Frequency 32MHz
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 512 x 8
Speed 32MHz
Number of I/O 25
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code S-PQCC-N28
Base Part Number PIC16F15354
Terminal Pitch 0.65mm
Supply Voltage 3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
HTS Code 8542.31.00.01
Additional Feature OPERATES AT 2.3 V MINIMUM SUPPLY AT 16 MHZ
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 16F
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 28-VQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
