PIC16F15324-E/7NVAO
RoHS
RoHS compliant
RoHS compliantPackage 16-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
RoHS Compliant NO LEAD QUAD CMOS Microcontroller -40C~125C TA 32MHz 1mm 512x 8
PDF
/
Inventory: 3935
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 1mm
Technical
Screening Level TS 16949
On Chip Program ROM Width 14
DAC Channels YES
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 11x10b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 7KB 4K x 14
Core Size 8-Bit
Program Memory Type FLASH
Clock Frequency 32MHz
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 512 x 8
Speed 32MHz
Number of I/O 12
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code S-PQCC-N16
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code compliant
Terminal Pitch 0.65mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q100, PIC? 16F
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case 16-VQFN Exposed Pad
Mounting Type Surface Mount
