PIC16F1527-I/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC; MCU; nanoWatt; 8-Bit; Flash; 28KB; 5MIPS; 2.3-5.5V; 30-CH; 10-Bit A/D; QFN-64
PDF
/
Buying Options
Total Price: USD $2.55
Unit Price: USD $2.552
≥1 USD $2.552
≥10 USD $2.3408
≥100 USD $2.1296
Inventory: 63
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 64
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2010
Series PIC? XLP? 16F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.5mm
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16F1527
Pin Count 64
Supply Voltage-Max (Vsup) 5.5V
Interface I2C, LIN, SPI, UART, USART
Memory Size 28kB
Oscillator Type Internal
Number of I/O 54
Nominal Supply Current 1mA
RAM Size 1.5K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Number of Bits 8
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 28KB 16K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 30x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
Number of Timers/Counters 9
Address Bus Width 8b
CPU Family PIC
Number of A/D Converters 1
Number of ADC Channels 30
Number of PWM Channels 10
Number of I2C Channels 2
Dimensions
Height 939.8μm
Length 8.9916mm
Width 8.9916mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
