PIC16F1458-E/SO
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB FLASH 20SOIC
PDF
/
Inventory: 6979
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Core Architecture PIC
Data Bus Width 8b
Data Converter A/D 9x10b; D/A 1x5b
Connectivity I2C, LINbus, SPI, UART/USART, USB
Program Memory Size 7KB 4K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 512 x 8
Speed 48MHz
Number of I/O 17
Oscillator Type Internal
Base Part Number PIC16F1458
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PIC? XLP? 16F
Published 2011
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Supplier Device Package 20-SOIC
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
