PIC16F1455-I/JQ
RoHS
RoHS compliant
RoHS compliantPackage 16-UQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-Bit PIC16 PIC RISC 14KB Flash 3.3V/5V 16-Pin UQFN EP Tube
PDF
/
Inventory: 9879
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Power Dissipation 800mW
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Pitch 0.65mm
Frequency 48MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PIC16F1455
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.7V
Interface I2C, LIN, SPI, UART, USART, USB
Memory Size 14kB
Oscillator Type Internal
Number of I/O 8
JESD-609 Code e3
Series PIC? XLP? 16F
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C TA
Number of Programmable I/O 11
On Chip Program ROM Width 14
Number of Timers/Counters 3
DAC Channels YES
PWM Channels YES
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 5x10b; D/A 1x5b
Bit Size 8
Connectivity I2C, LINbus, SPI, UART/USART, USB
Program Memory Size 14KB 8K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 1K x 8
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-UQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 4mm
Height Seated (Max) 0.55mm
