PIC16CE625-20I/P
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-bit PIC16 PIC RISC 3.5KB EPROM 3.3V/5V 18-Pin PDIP Tube
PDF
/
Inventory: 2822
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case 18-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 18
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 1999
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
CPU Family PIC
On Chip Program ROM Width 14
EEPROM Size 128 x 8
ROM (words) 2048
Number of Timers/Counters 1
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Access Time 20 μs
Watchdog Timer Yes
Bit Size 8
Supply Current-Max 7.5mA
Program Memory Size 3.5KB 2K x 14
Core Size 8-Bit
Program Memory Type OTP
Peripherals Brown-out Detect/Reset, POR, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 3V~5.5V
RAM Size 128 x 8
Number of I/O 13
Oscillator Type External
Memory Size 3.5kB
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 18
Base Part Number PIC16CE625
Frequency 20MHz
Terminal Pitch 2.54mm
Supply Voltage 5V
Terminal Position DUAL
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 22.8mm
Height Seated (Max) 4.32mm
