PIC16CE624T-04/SS
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU OTP 1KX14 EE COMP 20SSOP
PDF
/
Inventory: 3774
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 7.2mm
Height Seated (Max) 2mm
Technical
CPU Family PIC
On Chip Program ROM Width 14
EEPROM Size 128 x 8
ROM (words) 1024
Number of Timers/Counters 8
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Access Time 4 μs
Watchdog Timer Yes
Bit Size 8
Program Memory Size 1.75KB 1K x 14
Core Size 8-Bit
Program Memory Type OTP
Peripherals Brown-out Detect/Reset, POR, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 3V~5.5V
Memory Type EPROM
RAM Size 96 x 8
Speed 1 MHz
Number of I/O 13
Oscillator Type External
Memory Size 1.8kB
Supply Voltage-Min (Vsup) 3V
Power Supplies 3.3/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 20
Base Part Number PIC16CE624
Time@Peak Reflow Temperature-Max (s) 40
Frequency 4MHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16C
Published 1999
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
