PIC16C774T-I/L
RoHS
RoHS compliant
RoHS compliantPackage 44-LCC (J-Lead)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant J BEND QUAD Microcontroller 20mus 1W -40C~85C TA 20MHz
PDF
/
Inventory: 9232
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 44-LCC (J-Lead)
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 1999
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Terminal Finish MATTE TIN
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 245
Supply Voltage 5V
Terminal Pitch 1.27mm
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16C774
Pin Count 44
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Interface I2C, SPI, SSP, UART, USART
Memory Size 7kB
Oscillator Type External
Number of I/O 33
RAM Size 256 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 4V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 7KB 4K x 14
Connectivity I2C, SPI, UART/USART
Bit Size 8
Data Converter A/D 10x12b
Watchdog Timer Yes
Access Time 20 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 4096
On Chip Program ROM Width 14
Dimensions
Height Seated (Max) 4.57mm
Length 16.59mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
