PIC16C770/SS
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB OTP 20SSOP
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 29
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Number of Pins 20
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 1996
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn)
Additional Feature CAN ALSO OPERATE AT 2.5V MIN SUPPLY
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16C770
Pin Count 20
Operating Supply Voltage 5V
Power Supplies 5V
Interface I2C, SPI, SSP
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 15
RAM Size 256 x 8
Memory Type EPROM, OTP
Voltage - Supply (Vcc/Vdd) 4V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, SPI
Bit Size 8
Data Converter A/D 6x12b
Watchdog Timer Yes
Access Time 20 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
On Chip Program ROM Width 14
CPU Family PIC
Number of Programmable I/O 16
Dimensions
Height Seated (Max) 1.98mm
Length 7.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
