PIC16C72-10E/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU OTP 2KX14 A/D PWM 28SSOP
PDF
/
Inventory: 5080
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Number of Pins 28
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 1997
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 10MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16C72
Pin Count 28
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.5V
Interface I2C, SPI, SSP
Memory Size 2kB
Oscillator Type External
Number of I/O 22
RAM Size 128 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 4V~6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, SPI
Supply Current-Max 10mA
Bit Size 8
Data Converter A/D 5x8b
Watchdog Timer Yes
Access Time 10 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 2048
On Chip Program ROM Width 14
CPU Family PIC
Dimensions
Height Seated (Max) 1.99mm
Length 10.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
