PIC16C65B-04E/P

Microchip Technology
RoHS
RoHS RoHS compliant
Package 40-DIP (0.600, 15.24mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description IC MCU 8BIT 7KB OTP 40DIP
PDF
/
Inventory: 8208
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Through Hole
Package / Case 40-DIP (0.600, 15.24mm)
Surface Mount NO
Number of Pins 40

Technical

Operating Temperature -40°C~125°C TA
Packaging Tube
Published 1999
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 40
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 2.54mm
Frequency 4MHz
Base Part Number PIC16C65B
Pin Count 40
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4V
Interface I2C, SPI, UART, USART
Memory Size 7kB
Oscillator Type External
Number of I/O 33
RAM Size 192 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 4V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 7KB 4K x 14
Connectivity I2C, SPI, UART/USART
Bit Size 8
Watchdog Timer Yes
Access Time 4 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
CPU Family PIC

Dimensions

Length 52.26mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
