PIC16C65A-04E/PQ
RoHS
RoHS compliant
RoHS compliantPackage 44-QFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB OTP 44MQFP
PDF
/
Inventory: 3917
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 44-QFP
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~125°C TA
Packaging Tray
Published 1997
Series PIC? 16C
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.8mm
Frequency 4MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16C65A
Pin Count 44
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4V
Interface I2C, SPI, UART, USART
Memory Size 7kB
Oscillator Type External
Number of I/O 33
RAM Size 192 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 4V~6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 7KB 4K x 14
Connectivity I2C, SPI, UART/USART
Supply Current-Max 5mA
Bit Size 8
Watchdog Timer Yes
Access Time 4 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 4096
CPU Family PIC
Dimensions
Length 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
