PIC16C62B-20/SP
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB OTP 28SDIP
PDF
/
Buying Options
Total Price: USD $3.65
Unit Price: USD $3.652
≥1 USD $3.652
Inventory: 843
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 28-DIP (0.300, 7.62mm)
Number of Pins 28
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 2016
Series PIC? 16C
JESD-609 Code e0
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 28
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Microcontrollers
Max Power Dissipation 1W
Technology CMOS
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 2.54mm
Frequency 20MHz
Base Part Number PIC16C62B
Power Supplies 5V
Interface I2C, SPI, SSP
Memory Size 3.5kB
Oscillator Type External
Number of I/O 22
Nominal Supply Current 2mA
RAM Size 128 x 8
Memory Type EPROM, OTP
Voltage - Supply (Vcc/Vdd) 4V~5.5V
Number of Bits 8
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, SPI
Bit Size 8
Watchdog Timer Yes
Access Time 20 μs
Data Bus Width 8b
Number of Timers/Counters 3
Address Bus Width 8b
CPU Family PIC
ROM Programmability UVPROM
Number of SPI Channels 1
Number of USB Channels 0
Dimensions
Height 3.43mm
Length 35.18mm
Width 8.51mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
