PIC16C58B/JW
RoHS
/
Package 18-CDIP (0.300, 7.62mm) Window
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3KB EPROM/UV 18CDIP
PDF
/
Inventory: 7205
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 18-CDIP (0.300, 7.62mm) Window
Surface Mount NO
Number of Pins 18
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 2002
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 2.54mm
Frequency 20MHz
Base Part Number PIC16C58B
Pin Count 18
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.3/5V
Supply Voltage-Min (Vsup) 4.5V
Memory Size 2kB
Oscillator Type External
Number of I/O 12
RAM Size 73 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals POR, WDT
Program Memory Type EPROM, UV
Core Size 8-Bit
Program Memory Size 3KB 2K x 12
Supply Current-Max 16mA
Bit Size 8
Watchdog Timer Yes
Access Time 20 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 8
On Chip Program ROM Width 12
CPU Family PIC
ROM Programmability UVPROM
Dimensions
Height Seated (Max) 4.95mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
