PIC16C57CT-20E/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3KB OTP 28SOIC
PDF
/
Inventory: 6091
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Memory Size 2kB
Oscillator Type External
Number of I/O 20
RAM Size 72 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 3KB 2K x 12
Bit Size 8
Watchdog Timer Yes
Access Time 20 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 1
On Chip Program ROM Width 12
CPU Family PIC
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 2.5/6.25V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code R-PDSO-G28
Pin Count 28
Base Part Number PIC16C57C
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16C
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Dimensions
Height Seated (Max) 2.64mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Surface Mount YES
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
