PIC16C56A-20/P

Microchip Technology
RoHS
RoHS RoHS compliant
Package 18-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description IC MCU 8BIT 1.5KB OTP 18DIP
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.1472
≥1 USD $2.1472
Inventory: 325
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 6.6mm
Length 22.99mm
Height 3.68mm

Technical

CPU Family PIC
Address Bus Width 8b
Number of Timers/Counters 1
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Access Time 20 μs
Watchdog Timer Yes
Bit Size 8
Program Memory Size 1.5KB 1K x 12
Core Size 8-Bit
Program Memory Type OTP
Peripherals POR, WDT
Core Processor PIC
Number of Bits 8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 3V~5.5V
Memory Type EPROM, OTP
RAM Size 25 x 8
Nominal Supply Current 2mA
Number of I/O 12
Oscillator Type External
Memory Size 1kB
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 18
Base Part Number PIC16C56A
Frequency 20MHz
Terminal Pitch 2.54mm
Supply Voltage 5V
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16C
Packaging Tube
Operating Temperature 0°C~70°C TA

Physical

Number of Pins 18
Package / Case 18-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 6 Weeks
