PIC16C56-LPE/P
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 1.5KB OTP 18DIP
PDF
/
Inventory: 5630
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 22.8mm
Height Seated (Max) 4.32mm
Technical
On Chip Data RAM Width 8
RAM (words) 25
Number of Timers/Counters 1
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Access Time 40 ms
Watchdog Timer Yes
Bit Size 8
Program Memory Size 1.5KB 1K x 12
Core Size 8-Bit
Program Memory Type OTP
Peripherals POR, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~6V
Memory Type EPROM
RAM Size 25 x 8
Speed 40 MHz
Number of I/O 12
Oscillator Type External
Memory Size 1kB
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 6V
Pin Count 18
Base Part Number PIC16C56
Frequency 40kHz
Terminal Pitch 2.54mm
Supply Voltage 5V
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 800mW
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series PIC? 16C
Published 1998
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 18
Package / Case 18-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
