PIC16C56-HSE/P
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 1.5KB OTP 18DIP
PDF
/
Inventory: 4625
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 18-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 18
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2004
Series PIC? 16C
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 2.54mm
Frequency 16MHz
Base Part Number PIC16C56
Pin Count 18
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Memory Size 1kB
Oscillator Type External
Number of I/O 12
Speed 40 MHz
RAM Size 25 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 1.5KB 1K x 12
Bit Size 8
Watchdog Timer Yes
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 8
ROM (words) 1024
RAM (words) 25
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 4.32mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
