PIC16C55T-LP/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 768B OTP 28SSOP
PDF
/
Inventory: 3116
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Number of Pins 28
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Published 2002
Series PIC? 16C
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 40kHz
Base Part Number PIC16C55
Pin Count 28
Supply Voltage-Max (Vsup) 6.25V
Supply Voltage-Min (Vsup) 2.5V
Memory Size 512B
Oscillator Type External
Number of I/O 20
Speed 40 MHz
RAM Size 24 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 2.5V~6.25V
Core Processor PIC
Peripherals POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 768B 512 x 12
Bit Size 8
Watchdog Timer Yes
Access Time 40 ms
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 8
ROM (words) 512
RAM (words) 24
On Chip Data RAM Width 8
Dimensions
Length 10.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
