PIC16C54T-XTI/SO
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 768B OTP 18SOIC
PDF
/
Inventory: 7269
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 2.64mm
Technical
CPU Family PIC
On Chip Program ROM Width 12
ROM (words) 512
Number of Timers/Counters 1
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Access Time 4 μs
Watchdog Timer Yes
Bit Size 8
Program Memory Size 768B 512 x 12
Core Size 8-Bit
Program Memory Type OTP
Peripherals POR, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 3V~6.25V
RAM Size 25 x 8
Number of I/O 12
Oscillator Type External
Memory Size 768B
Supply Voltage-Min (Vsup) 3V
Power Supplies 2.5/6.25V
Supply Voltage-Max (Vsup) 6.25V
Pin Count 18
Base Part Number PIC16C54
Time@Peak Reflow Temperature-Max (s) 40
Frequency 4MHz
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16C
Published 1998
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 18
Surface Mount YES
Package / Case 18-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
