PIC16C54T-LPI/SO
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant GULL WING DUAL Microcontroller 40ms 800mW -40C~85C TA 40kHz
PDF
/
Inventory: 1953
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 2.64mm
Technical
On Chip Data RAM Width 8
RAM (words) 25
ROM (words) 512
Number of Timers/Counters 1
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Access Time 40 ms
Watchdog Timer Yes
Bit Size 8
Program Memory Size 768B 512 x 12
Core Size 8-Bit
Program Memory Type OTP
Peripherals POR, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~6.25V
Memory Type EPROM
RAM Size 25 x 8
Speed 40 MHz
Number of I/O 12
Oscillator Type External
Memory Size 512B
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 6.25V
Pin Count 18
Base Part Number PIC16C54
Frequency 40kHz
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 800mW
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series PIC? 16C
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 18-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
