PIC16C54A-10E/P
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 768B OTP 18DIP
PDF
/
Inventory: 6798
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 18-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 18
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2002
Series PIC? 16C
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 18
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 2.54mm
Frequency 10MHz
Base Part Number PIC16C54A
Pin Count 18
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.5V
Memory Size 512B
Oscillator Type External
Number of I/O 12
RAM Size 25 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 768B 512 x 12
Bit Size 8
Watchdog Timer Yes
Access Time 10 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 1
ROM (words) 512
On Chip Program ROM Width 12
CPU Family PIC
Dimensions
Height Seated (Max) 4.32mm
Length 22.8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
