PIC16C54A-04E/SS

Microchip Technology
RoHS
RoHS RoHS compliant
Package 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description IC MCU 8BIT 768B OTP 20SSOP
PDF
/
Inventory: 2554
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 4MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC16C54A
Pin Count 20
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.5/5.5V
Supply Voltage-Min (Vsup) 3.5V
Memory Size 512B
Oscillator Type External
Number of I/O 12
RAM Size 25 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 768B 512 x 12
Supply Current-Max 3.3mA
Bit Size 8
Watchdog Timer Yes
Access Time 4 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
Technology CMOS
Max Power Dissipation 800mW
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 16C
Published 2002
Packaging Tube
Operating Temperature -40°C~125°C TA
DAC Channels NO
Number of Timers/Counters 1
ROM (words) 512
On Chip Program ROM Width 12
CPU Family PIC

Physical

Number of Pins 20
Surface Mount YES
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount

Dimensions

Length 7.2mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
