PIC14000-20/SP
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 7KB OTP 28SDIP
PDF
/
Inventory: 4649
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 34.67mm
Height Seated (Max) 4.06mm
Technical
Number of Programmable I/O 22
CPU Family PIC
On Chip Program ROM Width 14
ROM (words) 4096
Number of Timers/Counters 1
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Access Time 20 μs
Data Converter Slope A/D
Bit Size 8
Connectivity I2C
Program Memory Size 7KB 4K x 14
Core Size 8-Bit
Program Memory Type OTP
Peripherals POR, Temp Sensor, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.7V~6V
Memory Type EPROM
RAM Size 192 x 8
Number of I/O 20
Oscillator Type Internal
Memory Size 7kB
Interface I2C, SPI, UART
Power Supplies 5V
Operating Supply Voltage 5V
Pin Count 28
Base Part Number PIC14000
Frequency 20MHz
Terminal Pitch 2.54mm
Supply Voltage 5V
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1W
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series PIC? 14
Published 1996
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 28
Package / Case 28-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
