PIC12LF1612-E/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING DUAL CMOS Microcontroller -40C~125C TA 32MHz 1.75mm 256x 8
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.994768
≥1 USD $0.994768
≥10 USD $0.938459
≥100 USD $0.885342
≥500 USD $0.835225
≥1000 USD $0.787948
Inventory: 8984
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Weight 540.001716mg
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2014
Series PIC? 12F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Matte Tin (Sn)
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 1.27mm
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC12LF1612
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 6
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Bit Size 8
Data Converter A/D 4x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
Number of Timers/Counters 5
Number of ADC Channels 4
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
