PIC12F683-E/MD
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB FLASH 8DFN
PDF
/
Buying Options
Total Price: USD $2.5
Unit Price: USD $2.4992
≥1 USD $2.4992
≥10 USD $2.4376
≥100 USD $2.3584
Inventory: 320
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VDFN Exposed Pad
Number of Pins 8
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2007
Series PIC? 12F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC12F683
Pin Count 8
Operating Supply Voltage 5V
Interface RS-232, USB
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 5
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Bit Size 8
Data Converter A/D 4x10b
Watchdog Timer Yes
Access Time 20 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
EEPROM Size 256 x 8
On Chip Program ROM Width 14
CPU Family PIC
Number of Programmable I/O 6
Dimensions
Height Seated (Max) 1mm
Length 4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
