PIC12F609-E/MD
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 1.75KB FLASH 8DFN
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.623628
≥1 USD $0.623628
≥10 USD $0.512031
≥30 USD $0.456889
≥100 USD $0.401747
≥500 USD $0.368925
≥1000 USD $0.35317
Inventory: 9735
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VDFN Exposed Pad
Number of Pins 8
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2006
Series PIC? 12F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC12F609
Pin Count 8
Interface RS-232, USB
Memory Size 1.8kB
Oscillator Type Internal
Number of I/O 5
RAM Size 64 x 8
Voltage - Supply (Vcc/Vdd) 2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 1.75KB 1K x 14
Bit Size 8
Watchdog Timer Yes
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 2
On Chip Program ROM Width 14
CPU Family PIC
Dimensions
Height Seated (Max) 1mm
Length 4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
