PIC12F510T-I/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 1.5 KB 38 RAM 6 I/O Ind Temp SOIC8
PDF
/
Buying Options
Total Price: USD $0.89
Unit Price: USD $0.8888
≥1 USD $0.8888
≥10 USD $0.8008
≥100 USD $0.77
Inventory: 7310
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2005
Series PIC? 12F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature ALSO OPERATES AT MINIMUM 2V AT 4MHZ
Subcategory Microcontrollers
Max Power Dissipation 700mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Frequency 8MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC12F510
Pin Count 8
Memory Size 1.5kB
Oscillator Type Internal
Number of I/O 5
RAM Size 38 x 8
Voltage - Supply (Vcc/Vdd) 2V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals POR, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 1.5KB 1K x 12
Supply Current-Max 2mA
Bit Size 8
Data Converter A/D 4x8b
Watchdog Timer Yes
Access Time 20 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 1
On Chip Program ROM Width 12
CPU Family PIC
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 4.9mm
