PIC12F1822T-I/RF
RoHS
RoHS compliant
RoHS compliantPackage 8-UDFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB FLASH 8UDFN
PDF
/
Inventory: 8378
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-UDFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2010
Series PIC? XLP? 12F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC12F1822
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.5V
Interface I2C, LIN, SPI, UART, USART
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 6
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 4x10b; D/A 1x5b
Has ADC YES
DMA Channels NO
PWM Channels NO
ROM (words) 2048
EEPROM Size 256 x 8
Dimensions
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
