PIC12F1822-E/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB FLASH 8DIP
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.4344
≥1 USD $1.4344
≥10 USD $1.3112
≥100 USD $1.2056
Inventory: 1252
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 8
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2010
Series PIC? XLP? 12F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 800mW
Technology CMOS
Terminal Position DUAL
Supply Voltage 2.3V
Frequency 32MHz
Base Part Number PIC12F1822
Pin Count 8
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Interface I2C, LIN, SPI, UART, USART
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 6
Nominal Supply Current 145μA
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 4x10b; D/A 1x5b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
Number of Timers/Counters 3
Address Bus Width 8b
EEPROM Size 256 x 8
CPU Family PIC
Number of ADC Channels 4
Number of I2C Channels 1
Dimensions
Height 4.953mm
Length 10.16mm
Width 7.112mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
