PIC12F1572-I/MF
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB FLASH 8DFN
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.8976
≥1 USD $0.8976
≥10 USD $0.8096
≥100 USD $0.7304
Inventory: 547
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 2mm
Length 3mm
Height 850μm
Technical
Number of USB Channels 1
Number of PWM Channels 3
Number of ADC Channels 4
Number of UART Channels 0
CPU Family PIC
Number of Timers/Counters 6
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 4x10b; D/A 1x5b
Bit Size 8
Supply Current-Max 7.5mA
Connectivity LINbus, UART/USART
Program Memory Size 3.5KB 2K x 14
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~5.5V
RAM Size 256 x 8
Number of I/O 6
Oscillator Type Internal
Memory Size 3.5kB
Interface LIN, UART, USART
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 2.5/5V
Supply Voltage-Max (Vsup) 5.5V
Base Part Number PIC12F1572
Time@Peak Reflow Temperature-Max (s) 40
Frequency 32MHz
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? 12F
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Weight 37.393021mg
Number of Pins 8
Surface Mount YES
Package / Case 8-VDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
