PIC12CE674-10E/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 3.5KB OTP 8DIP
PDF
/
Inventory: 1412
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 1997
Series PIC? 12C
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 700mW
Technology CMOS
Terminal Position DUAL
Supply Voltage 5V
Frequency 10MHz
Base Part Number PIC12CE674
Pin Count 8
Power Supplies 5V
Memory Size 3.5kB
Oscillator Type Internal
Number of I/O 5
RAM Size 128 x 8
Memory Type FLASH
Voltage - Supply (Vcc/Vdd) 3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 3.5KB 2K x 14
Bit Size 8
Data Converter A/D 4x8b
Watchdog Timer Yes
Access Time 10 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
EEPROM Size 16 x 8
CPU Family PIC
Number of A/D Converters 1
Number of ADC Channels 4
Dimensions
Height 3.17mm
Length 9.78mm
Width 6.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
