PIC12C509T-04/SM
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 1.5KB OTP 8SOIJ
PDF
/
Inventory: 5399
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.209, 5.30mm Width)
Number of Pins 8
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Published 1999
Series PIC? 12C
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 700mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Frequency 4MHz
Base Part Number PIC12C509
Pin Count 8
Memory Size 1.5kB
Oscillator Type Internal
Number of I/O 5
RAM Size 41 x 8
Memory Type EPROM
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals POR, WDT
Program Memory Type OTP
Core Size 8-Bit
Program Memory Size 1.5KB 1K x 12
Supply Current-Max 2.4mA
Bit Size 8
Watchdog Timer Yes
Access Time 4 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels NO
DAC Channels NO
Number of Timers/Counters 1
On Chip Program ROM Width 12
CPU Family PIC
Dimensions
Height Seated (Max) 2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
