PIC12C509-04I/P
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 1.5KB OTP 8DIP
PDF
/
Buying Options
Total Price: USD $4.3
Unit Price: USD $4.2959
≥1 USD $4.2959
≥10 USD $3.52545
≥100 USD $3.41525
≥500 USD $3.30505
≥1000 USD $3.19485
Inventory: 163
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 1999
Series PIC? 12C
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Max Power Dissipation 700mW
Technology CMOS
Terminal Position DUAL
Supply Voltage 5V
Frequency 4MHz
Base Part Number PIC12C509
Pin Count 8
Memory Size 1.5kB
Oscillator Type Internal
Number of I/O 5
RAM Size 41 x 8
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
CPU Family PIC
Number of Timers/Counters 1
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC NO
Access Time 4 μs
Watchdog Timer Yes
Bit Size 8
Supply Current-Max 2.4mA
Program Memory Size 1.5KB 1K x 12
Core Size 8-Bit
Program Memory Type OTP
Peripherals POR, WDT
Core Processor PIC
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.6mm
Length 9.78mm
Height 3.17mm
