DSPIC33FJ64MC804-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MICROCHIP - DSPIC33FJ64MC804-I/ML - DSC, 16BIT, 64K FLASH, 40MIPS, 44QFN
PDF
/
Buying Options
Total Price: USD $6.5
Unit Price: USD $6.5032
≥1 USD $6.5032
≥10 USD $5.9752
≥100 USD $5.4208
Inventory: 296
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 8mm
Length 8mm
Height 880μm
Technical
Number of SPI Channels 2
Number of I2C Channels 1
Number of External Interrupts 3
Number of Serial I/Os 2
Integrated Cache NO
Format FLOATING-POINT
Low Power Mode YES
Boundary Scan YES
Density 512 kb
Number of Timers/Counters 5
DAC Channels YES
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 9x10b/12b; D/A 6x16b
Bit Size 16
Supply Current-Max 76mA
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 64KB 64K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, QEI, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 16K x 8
Number of I/O 35
Oscillator Type Internal
Memory Size 64kB
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 44
Base Part Number DSPIC33FJ64MC804
Time@Peak Reflow Temperature-Max (s) 40
Frequency 40MHz
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 44
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series dsPIC? 33F
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 44
Package / Case 44-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
