DSPIC33FJ32MC101-E/SS
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 32KB FLASH 20SSOP
PDF
/
Inventory: 5762
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Published 2012
Packaging Tube
Operating Temperature -40°C~125°C TA
Screening Level TS 16949
Max Frequency 32MHz
On Chip Program ROM Width 8
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 6x10b
Bit Size 16
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 32KB 11K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, Motor Control PWM, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 1K x 16
Speed 16 MIPs
Number of I/O 15
Oscillator Type Internal
Memory Size 32kB
Interface I2C, IrDA, LIN, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
JESD-30 Code R-PDSO-G20
Base Part Number DSPIC33FJ32MC101
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Terminal Finish Matte Tin (Sn)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series Automotive, AEC-Q100, dsPIC? 33F
Physical
Surface Mount YES
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 7.2mm
Height Seated (Max) 2mm
