DSPIC33FJ32GP102-E/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-bit dsPIC33F dsPIC RISC 32KB Flash 3.3V Automotive 28-Pin SOIC W Tube
PDF
/
Inventory: 5403
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 28
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2012
Series Automotive, AEC-Q100, dsPIC? 33F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Terminal Finish Matte Tin (Sn)
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number DSPIC33FJ32GP102
Operating Supply Voltage 3.3V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 21
RAM Size 1K x 16
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 32KB 11K x 24
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Supply Current-Max 22mA
Bit Size 16
Data Converter A/D 8x10b
RAM (words) 2048
Format FIXED-POINT
Number of Timers/Counters 5
Data Bus Width 16b
Watchdog Timer Yes
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
