DSPIC33FJ256GP506AT-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 256KB FLASH 64TQFP
PDF
/
Buying Options
Total Price: USD $110.6
Unit Price: USD $110.5971
≥1 USD $110.5971
≥10 USD $106.9111
≥100 USD $95.8512
Inventory: 1190
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10mm
Height Seated (Max) 1.2mm
Technical
Format FIXED-POINT
Number of Timers/Counters 9
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 18x10b/12b
Bit Size 16
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 256KB 256K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals AC'97, Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 16K x 8
Number of I/O 53
Oscillator Type Internal
Memory Size 256kB
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 64
Base Part Number DSPIC33FJ256GP506A
Time@Peak Reflow Temperature-Max (s) 40
Frequency 40MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
HTS Code 8542.31.00.01
Terminal Finish Matte Tin (Sn)
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series dsPIC? 33F
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 64
Surface Mount YES
Package / Case 64-TQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
