DSPIC33FJ16GS504-E/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 16KB FLASH 44TQFP
PDF
/
Buying Options
Total Price: USD $6.16
Unit Price: USD $6.16
≥1 USD $6.16
≥10 USD $5.6408
≥100 USD $5.104
Inventory: 201
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Number of Programmable I/O 35
Max Frequency 40MHz
Core Architecture dsPIC
Density 128 kb
Number of Timers/Counters 3
Data Bus Width 16b
Watchdog Timer Yes
Data Converter A/D 24x10b; D/A 4x10b
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 16KB 16K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor dsPIC
Voltage - Supply (Vcc/Vdd) 3V~3.6V
Memory Type FLASH
RAM Size 2K x 8
Speed 40 MIPs
Number of I/O 35
Oscillator Type Internal
Memory Size 16kB
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Interface I2C, IrDA, LIN, SPI, UART, USART
Operating Supply Voltage 3.3V
Base Part Number DSPIC33FJ16GS504
Frequency 40MHz
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100, dsPIC? 33F
Published 2007
Packaging Tray
Operating Temperature -40°C~125°C TA
Physical
Supplier Device Package 44-TQFP (10x10)
Number of Pins 44
Package / Case 44-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
Alternative Model
