DSPIC33FJ16GP101-E/P
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Digital Signal Processors & Controllers - DSP, DSC 16bit DSC Fam 16MIPS 16KB FL 1KB RAM
PDF
/
Inventory: 7623
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 18-DIP (0.300, 7.62mm)
Number of Pins 18
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2011
Series Automotive, AEC-Q100, dsPIC? 33F
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
Terminal Finish MATTE TIN
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position DUAL
Supply Voltage 3.3V
Terminal Pitch 2.54mm
Frequency 32MHz
Base Part Number DSPIC33FJ16GP1
Pin Count 18
Operating Supply Voltage 3.3V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 16kB
Oscillator Type Internal
Number of I/O 13
Speed 16 MHz
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 16KB 16K x 8
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Supply Current-Max 21mA
Bit Size 16
Data Converter A/D 4x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 5461
On Chip Program ROM Width 24
Number of Programmable I/O 35
Format FIXED-POINT
RAM (words) 1024
Dimensions
Length 22.86mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
