DSPIC33FJ128GP710AT-I/PF
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 128KB FLASH 100TQFP
PDF
/
Inventory: 2818
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-TQFP
Number of Pins 100
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2009
Series dsPIC? 33F
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Terminal Finish Matte Tin (Sn)
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 40MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number DSPIC33FJ128GP710A
Pin Count 100
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART
Memory Size 128kB
Oscillator Type Internal
Number of I/O 85
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals AC'97, Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 128KB 128K x 8
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 16
Data Converter A/D 32x10b/12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 9
Format FIXED-POINT
Dimensions
Height Seated (Max) 1.2mm
Length 14mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
