DSPIC33FJ06GS202AT-E/SS
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 7168
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
On Chip Data RAM Width 16
Number of External Interrupts 3
Number of Serial I/Os 1
RAM (words) 512
Integrated Cache NO
Number of Programmable I/O 21
Low Power Mode NO
Boundary Scan YES
On Chip Program ROM Width 24
Core Architecture dsPIC
Number of Timers/Counters 2
DAC Channels YES
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Frequency (Max) 50kHz
Bit Size 16
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Memory Type FLASH
RAM Size 1kB
Number of I/O 21
Memory Size 6kB
Min Supply Voltage 3V
Max Supply Voltage 3.6V
Interface I2C, IrDA, LIN, SPI, UART, USART
Temperature Grade INDUSTRIAL EXTENDED
Operating Supply Voltage 3.3V
Frequency 40MHz
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Digital Signal Processors
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Number of Terminations 28
Packaging Tape and Reel
Physical
Number of Pins 28
Package / Case SSOP
Mount Surface Mount
