DSPIC33EV64GM102-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-bit dsPIC33E dsPIC CISC 64KB Flash 5V 28-Pin SOIC W
PDF
/
Buying Options
Total Price: USD $7.88
Unit Price: USD $7.876087
≥1 USD $7.876087
≥200 USD $3.048554
≥500 USD $2.940896
≥1000 USD $2.88838
Inventory: 1751
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 28
Weight 2.214806g
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2016
Series dsPIC? 33EV
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature A/D CONVERTERS IS ALSO AVAILABLE IN 11-CH 10-BIT, OPERATES UPTO 70MIPS
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 250
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number DSPIC33EV64GM1
Qualification Status Not Qualified
Operating Supply Voltage 5V
Power Supplies 5V
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 21
Speed 70 MIPs
RAM Size 8K x 8
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 64KB 22K x 24
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Supply Current-Max 31mA
Bit Size 16
Data Converter A/D 11x10/12b
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 9
ROM (words) 65536
On Chip Program ROM Width 8
Max Frequency 7.37MHz
Format FLOATING-POINT
Dimensions
Height Seated (Max) 2.65mm
Compliance
RoHS Status ROHS3 Compliant
