DSPIC33EV64GM004-H/PT
RoHS
/
Package TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 8305
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.2mm
Technical
ROM Programmability FLASH
RAM (bytes) 8192
RAM (words) 4096
Format FLOATING-POINT
Screening Level AEC-Q100; TS 16949
On Chip Program ROM Width 8
ROM (words) 65536
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Bit Size 16
Supply Current-Max 25mA
Clock Frequency 40MHz
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Speed 40 MHz
Number of I/O 35
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade AUTOMOTIVE
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 150°C
Qualification Status Not Qualified
JESD-30 Code S-PQFP-G44
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.8mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
Additional Feature A/D CONVERTERS IS ALSO AVAILABLE IN 24-CH 10-BIT, OPERATES UPTO 40MIPS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3
JESD-609 Code e3
Physical
Surface Mount YES
Package / Case TQFP
