DSPIC33EV64GM002-E/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING DUAL CMOS Microcontroller -40C~125C TA 40MHz 2mm 8K x 8
PDF
/
Buying Options
Total Price: USD $7.72
Unit Price: USD $7.718539
≥1 USD $7.718539
≥200 USD $2.986848
≥500 USD $2.881816
≥1000 USD $2.830612
Inventory: 1427
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Surface Mount
Package / Case 28-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2016
Series Automotive, AEC-Q100, dsPIC? 33EV
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.65mm
Reach Compliance Code unknown
Base Part Number DSPIC33EV64GM0
JESD-30 Code R-PDSO-G28
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 21
Speed 60 MIPs
RAM Size 8K x 8
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Clock Frequency 40MHz
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 64KB 22K x 24
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 16
Data Converter A/D 11x10/12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
On Chip Program ROM Width 8
Screening Level AEC-Q100; TS 16949
Dimensions
Height Seated (Max) 2mm
Length 10.2mm
Width 5.3mm
Compliance
RoHS Status ROHS3 Compliant
