DSPIC33EV128GM004-H/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FLOATING-POINT ROHS3Compliant GULL WING QUAD Microcontroller 5V -40C~150C TA 25mA 40MHz
PDF
/
Inventory: 9455
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 44-TQFP
Surface Mount YES
Technical
Operating Temperature -40°C~150°C TA
Packaging Tray
Series Automotive, AEC-Q100, dsPIC? 33EV
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature A/D CONVERTERS IS ALSO AVAILABLE IN 24-CH 10-BIT, OPERATES UPTO 40MIPS
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.8mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number DSPIC33EV128GM0
JESD-30 Code S-PQFP-G44
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.5V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 128kB
Oscillator Type Internal
Number of I/O 35
Speed 40 MIPs
RAM Size 8K x 8
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Clock Frequency 40MHz
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 128KB 43K x 24
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Supply Current-Max 25mA
Bit Size 16
Data Converter A/D 24x10/12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
ROM (words) 131072
On Chip Program ROM Width 8
Screening Level AEC-Q100; TS 16949
Format FLOATING-POINT
RAM (words) 4096
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Width 10mm
Compliance
RoHS Status ROHS3 Compliant
