DSPIC33EP512MC204-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Digital Signal Processors & Controllers - DSP, DSC 16B DSC 512KB Flsh 48KB RAM MCPWM QEI
PDF
/
Inventory: 5480
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 8mm
Height Seated (Max) 1mm
Technical
RAM (words) 24576
Format FLOATING-POINT
On Chip Program ROM Width 24
ROM (words) 174762
Number of Timers/Counters 12
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Data Converter A/D 9x10b/12b
Bit Size 16
Supply Current-Max 150mA
Connectivity I2C, IrDA, LINbus, QEI, SPI, UART/USART
Program Memory Size 512KB 170K x 24
Core Size 16-Bit
Program Memory Type FLASH
Clock Frequency 60MHz
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 24K x 16
Speed 70 MIPs
Number of I/O 35
Oscillator Type Internal
Memory Size 512kB
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART
Power Supplies 3.3V
Operating Supply Voltage 3.6V
Qualification Status Not Qualified
Base Part Number DSPIC33EP512MC204
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
HTS Code 8542.31.00.01
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code 3A001.A.3
Number of Terminations 44
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series dsPIC? 33EP
Published 2013
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 44
Surface Mount YES
Package / Case 44-VQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
